Features

ForeFront™ Suspension System

The system utilizes four upper and lower control rods and mower-specific shocks that ensure the front caster bearing remains vertical through the full range of travel. This controlled motion results in a smoother ride, more precise tracing of the terrain and an improved cut.

Vanguard BIG BLOCK™ Engine

The EFI-ETC engine with Oil Guard delivers a 500 hour oil change interval and 40 hp*, giving you added cutting performance to excel in thick, dense, and wet conditions. (select models)

Premium Suspension Seat

Select models feature the premium high-back suspension seat with armrests, adjustable lumbar and back recline. (ISX3300 also includes a headrest)

Hydro-Gear ZT-4400™ Transaxles

Dual-commercial transaxles with 8.3″ cooling fans to repel debris.

Adjustable Cut Height

Foot-operated deck lift, with adjustable pedal, can change cut height in 1/4″ increments from 1.5″- 5″.

Ride-On Mower Warranties

Coil-Over-Shocks and all suspension-related components are covered for 5 years (60 months), for unlimited hours. We are committed to providing performance, productivity and durability.

Specifications

Model Number5902080US MSRP ^$12,799.00Engine BrandKawasaki^® FT730V EFIEngine Power Rating *26Displacement (cc)726PTOElectricCylinders2StarterElectricFuel TypeGasolineFuel Tank Capacity (gal)11Hour Meter/InstrumentationDual-function hour meter, fuel level gauge in each tankCutting Width (in)60Cutting Height (in)1.5 – 5SpindlesCast-iron greaseableDeck ConstructioniCD™ Cutting System, 2-BeltSuspensionForeFront™ Suspension SystemTransmissionDual, commercial Hydro-Gear^® ZT-4400™ Transaxles with 8.3″ cooling fansDrive Axles (in)1.375Caster Tires (in)13 x 6.5-6Drive Tires (in)24 x 12-12Ground Speed-Fwd (mph)0-10Ground Speed-Rev (mph)0-5Overall Length (in)82.5Overall Width (in) Deflector Down/Deflector Up74 / 65Dry Weight (lbs)1302Seat PackagePremium high-back Suspension Seat with adjustable arm rests, adjustable lumbar and back recline.Certified Roll-over Protection System180° foldableControls / Safety GroupSeat activated engine kill, clutch safety switch, neutral and parking brake safety circuit/adjustable twin steering controlsParking Brake / Safety CircuitHand operated Internal transaxle brakeWarranty (Engine) †3-Year limited manufacturer’s warrantyWarranty (Balance of Machine) †4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over-shocks and all suspension related components are covered for 4 years (48 months) unlimited hours. Coverage on other components varies, please see operator’s manual for complete details.Engine ConfigurationKawasaki^®

Illustrated Parts List

Wiring Diagram Schematic

Attachments

Turbo-Pro™ or Fast-Vac® Triple Bag Soft Top Collection System 5601412

Tripe Bag Soft Top is simple to install. Each heavy-duty mesh has a rugged plyethylene underside with an integrated handle to assist with removal. Fits 52″ and 61″ models. Capacity: 13 cubic feet.

Turbo-Pro™ Double Bag Collection System

The double bag collection system is simple to install. Each heavy-duty mesh bag has a rugged polyethylene underside with integrated handle to assist with removal. Fits 52″ models.

Fast-Vac® EZ Dump™ Collection System 5601420

The EZ Dump™ increases productivity by giving the operator the ability to release grass clippings from the riding mower seat with the use of a toggle switch. The hopper is specially lined to ensure that all materials are dumped each time for increased productivity. The low profile of this system is better for visibility when compared to competitive commercial lawn mower attachments. Fits 52″ and 61″.

Striping Kit 5601385

Rubber flap lays down grass to create patterns across the landscape.

Mulch Kit 5601441

Select kits include dedicated mulching blades, baffles, hardware and instruction sheet.

Trailer Hitch Kit 5600031

Will accept a 1/2” shank ball and comes complete with hardware.

Flat-Free Caster Tires 5023279

Run all day with no flats, eliminates down time.

Service Jack 5601080, Mount 5601235 Need Both

Heavy-duty steel bracket and jack allows for easy and convenient access under the deck.

LED Light Kit 5600891

Energy efficient heavy-duty ROPS mounted LED light kit with simple instructions.
